Molding

Published on Friday, 23. August 2024

Content Guide：Everything we do at Slinar is focused on providing the fastest and highest quality prototypes and production parts in the industry. This demands the latest technology, managed by tight process controls

What is injection molding?

Injection molding injects molten plastic or other materials into a precision-machined mold cavity, where it cools and solidifies into the final part shape. It is the most common method for high-volume production of plastic parts.
When should I choose injection molding over CNC or 3D printing?

Choose injection molding when production volumes exceed 1,000 units and per-part cost justifies the tooling investment. CNC and 3D printing are more cost-effective for low-volume production.
What are the key constraints in injection molding design?

Draft direction for part release, undercuts requiring side actions, and uniform wall thickness to prevent sink marks and warpage. Pull direction and parting line should be decided early in design.
What is the typical lead time for injection molding?

Mold build time: 2 to 12 weeks depending on complexity. Production lead time after mold completion: 1-2 weeks for sampling and validation.
What are common injection molding defects?

Warpage, sink marks, short shots, jetting, flash, voids, and burns. All are prevented through process optimization and mold design refinement.
What surface finishes are available in injection molding?

As-molded, polished (mirror finish), textured (grain patterns from mold etching), and EDM finishes (spark texture for matte or stippled surfaces).
What materials can be injection molded?

All thermoplastics: ABS, polycarbonate, nylon, PEEK, acrylic, polyethylene, polypropylene, POM, and glass-filled grades. Elastomers and thermosets are also possible.
What is the difference between prototype tooling and production tooling?

Prototype tooling uses lower-cost aluminum molds with faster lead time but limited longevity (1,000-10,000 shots). Production tooling uses steel molds with longer lead time but high durability (100,000-1,000,000+ shots).
What is bridge production?

Bridge production uses lower-cost tooling to produce 500-5,000 parts while full production tooling is being built, enabling market launch and customer validation before full-scale production.
How do I get a molding quote?

Submit part geometry, annual quantity, material preference, and application description. The quote includes tooling cost, unit part price, estimated tool life, and lead time.
